Controller Cnc Milling For 5 Axis

CNC Milling Controller: 1) Support Dual analog voltage(0~10V)& C-axis for Spindle servo 2) Support RTCP mode 3) Support Stepper/Increment/Absolute/EtherCAT/Powerlink Servo for Feeding Axes 4) Scanning Function & Follow Mode & Auto Tool Setter/Probe

_20220707145050

Number of control axes	5 axes
Minimum programming	0.001mm
Maximum programming	± 99999.999mm
Top speed	30m / min
Feed speed	0.001-15m / min
Manual continuous	One axis or simultaneous multi-axis
Screen saver function	Screen saver function
Program editing	Male / English, relative / absolute programming
Pre-reading function	Short line preprocessing 10,000 lines
Compensation function	Knife compensation, between compensation, screw compensation, radius compensation
Communication function	RS232, U disk interface
Program editing	Male / English, relative / absolute programming
Tool functions:	1)Tool length compensation 2)Tool point radius compensation (C type)
Program operation	Create, edit, delete, rename, search, copy, copy, paste, read in, out, background editing, dynamic graphics simulation
High-speed and high-precision machining	G05 high-speed small line segment look-ahead, trajectory smoothing processing, look-ahead and pre-reading up to 1000 segments

1.-&(1000MC)(1)

3.-(1000MC)

GH-1000TC

Multiple function:

It can realize the drilling/boring,roughing of roungroove / rectanglegroove ,finishing of full circle /rectangle, continous drilling of straight line /rectangle /arc etc.

FAQ

Q1. Can I have a sample order for test?

A: Yes, we welcome sample order to test and check quality. We will provide the technical support. but if you does not have any basic knowledge,we do not suggest.

Q2. What about the lead time?

A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity.

Q3. How to proceed an order for our controller?

A: Firstly after you check our controller datasheet or you are familiar with the Mach3 controller,you can directly tell us how many axis you need or you can let us know your requirements or application and how many axis you need.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms and send the payment to us.
Fourthly We arrange the delivery.

If you have any questions, pls feel free to contact us. We'll be sure to get back to you within an hour on a business day.
